The Longi LR5-54HTH 435W solar panel is a small-sized photovoltaic module with high efficiency. Due to its compact design, it’s very popular in the Europe market, especially for Germany residential installation, and won great reputation.
Longi HiMO6 Explorer LR5-54HTH 435W solar panel is a high-quality photovoltaic module that offers numerous advantages for renewable energy systems.
Electrical Parameters (STC*)
Module model |
LR5-54HTH 415W |
LR5-54HTH 420W | LR5-54HTH 425W |
LR554HTH 430W
|
LR5-54HTH435W
|
Maximum Power (Pmax/W) | 415 | 420 | 425 | 430 | 435 |
Open circuit voltage (Voc/V) | 38.53 | 38.73 | 38.93 | 39.13 | 39.33 |
Short circuit current (Isc/A) | 13.92 | 14.00 | 14.07 | 14.15 | 14.22 |
Peak power voltage (Vmp/V) | 32.24 | 32.44 | 32.64 | 32.84 | 33.04 |
Peak power current (Imp/A) | 12.88 | 12.95 | 13.03 | 13.10 | 13.17 |
Module Efficiency (%) | 21.3 | 21.5 | 21.8 | 22.0 | 22.3 |
Power Output Tolerance (W) | 0~3% | ||||
Temperature Coefficient of Isc | +0.05%/°C | ||||
Temperature Coefficient of Voc | -0.23%/°C | ||||
Temperature Coefficient of Pmax | -0.29%/°C | ||||
Standard test conditions | STC:AM1.5 1000W/m² 25℃ |
The Longi LR5-54HTH 435W solar panel is a high-performance module that has great reputation from many markets, and the following are some main features:
–High Efficiency: The LR5-54HTH boasts a high conversion efficiency, utilizing advanced PERC (Passivated Emitter Rear Contact) solar cell technology. This enables it to convert a larger portion of sunlight into electricity, resulting in increased energy output.
–Superior Durability: The panel is constructed using high-quality materials that ensure long-term performance and durability. It features a 5BB (Busbar) design, which enhances reliability and reduces the impact of shading on power generation.
–Enhanced Low-Light Performance: The LR5-54HTH is designed to generate electricity even in low-light conditions. This makes it particularly suitable for installations in areas with variable weather patterns or regions that experience foggy or cloudy days.
–Excellent Temperature Coefficient: The module exhibits a low temperature coefficient, meaning it can maintain its efficiency even at high temperatures. This is particularly beneficial in hot climates where solar panels can be exposed to intense heat.
—Robust Frame Design: The solar panel is equipped with a sturdy frame that provides exceptional resistance against mechanical stress and harsh environmental conditions. The frame is designed to enable quick and easy installation, ensuring a secure fit.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
